| Input signal: | DMX512/RDM |
| Input voltage: | DC12V～DC24V |
| Max load current: | 3A × 32CH Max 96A |
| Max output power: | (0~36W…72W) × 32CH Max. 2304W |
| DMX512 socket : | 3-pin XLR, 5-pin XLR, RJ45, Green terminal |
| Gray scale level : | 8bit (256 levels) / 16bit (65536 levels) |
| Working temperature: | -30℃～65℃ |
| Package Size : | L313×W127×H41mm |
| Weight (G.W) : | 1180g |
<
